Monocrystalline efficient solar harvesting

Strong surface for harsh environment

Panels capable of 0 to +3 Watts over rated capacity

Pre-drilled aluminum frame

Tempered glass

25 Year limited warranty

Maximum Power (Watts): 120 watts

(Vmp): 18.5 volts operating voltage

(Imp): 6.49 amps operating current

(Voc): 22.2 volts open circuit voltage

(Isc): 7.14 amps

Solar Cell: 158.75mm x 105.83mm

Number of Cells (pcs): 9*4 = 36

Front Glass Thickness (mm): 3.2 mm

Temperature Coefficients of Isc (%) °C: -0.048

Temperature Coefficients of Voc (%) °C: -0.29

Temperature Coefficients of Pm (%) °C: -0.37

Temperature Range: -40°C to +80°C

Tolerance Wattage: 0-3 watts

Surface Maximum Load Capacity: 6000Pa snow and 3600Pa wind

Allowable Hail Load: 45mm at 30.7m/s

Bypass Diode Rating (A): 10

Cell Efficiency (%): 19.84%

Module Efficiency (%): 17.30%

Warranty: 91.2% of 12 years, 80.6% of 25 years

Weight Per Panel (lbs): 17 lbs

Dimensions (inches): 40.15 x 26.75 x 1.37

Additional information

Brand	AIMS Power
