Description
2500W max continuous power
Modified sine wave
Over Temperature protection
Over Load protection
Dual ac receptacle that can be split with a separate spliter if extra outlets are needed
On/off switch
Convenient always on dual cooling fan operation
Internally fuse protected
ac output short circuit protection
Auto reset on most fault conditions
Battery terminals are designed to conduct more current therefore requiring only one set of cables.
Aluminum case for optimal cooling
Pre-slotted mounting plate
Instruction manual
Free 1 year tech support
1 Year Warranty Parts and Labor
Continuous output power: 2500 Watts. Use 200 amp inline fuse.
Surge power capability (peak power): 5000 Watts
dc input / operating voltage: 10 to 15 Volts
Output voltage: 120 Volts ac +/- 10%
Output wave form: modified sine wave with phase correction
Output frequency: 60 Hz +/- 1 Hz
Battery low voltage alarm: 10.5 +/- 0.5 Volts
Battery low voltage shutdown: 10.0 +/- 0.5 Volts
AC amps: 21
DC amps: 208
No load current: 2.5 Amps with switch in the on position (because fans are always on) See PWRINV2500 if you don’t want always on fans.
Full load efficiency: 90%
1/3 load efficiency: 95%
No load minimum operating temperature: -15 degrees Celsius
Full load maximum operating temperature: 55 +/- 5 degrees Celsius (automatic shutdown)
AC Output Socket Type: dual Type 2 -3 prong
High input voltage protection: 15V-17V
Low input voltage shutdown: 10V
Internal fuse protection
Product size (L x W x H): 14.5”X 6.5”X 3.0”
Unit Weight: 6.1 lbs Boxed Weight: 8 lbs
UL maximum recommended per outlet 1500W
