5000W max continuous power
Modified sine wave
Volt meter on front panel to monitor your battery voltage
Amp meter on front panel to monitor your current use (rate at which battery is drained)
AC Direct Connect Terminal
Over Temperature LED indicator
Over Load LED indicator
Quadruple ac receptacle that can be used with any separate spliter to provide even more outlets
On/off switch
Over Temperature protection
Over Load protection
Single cooling fan operation thermally controlled
Internally fuse protected
ac output short circuit protection
Auto reset on most fault conditions
Aluminum case for optimal cooling
Pre-wired for remote on/off switch
Pre-slotted mounting plate
Instruction manual
Free 1 year tech support
1 Year Warranty Parts and Labor

Continuous output power: 5000 Watts

Surge power capability (peak power): 10,000 Watts

dc input / operating voltage: 20 to 32 Volts

Output voltage: 120 Volts ac +/- 10%

Output wave form: modified sine wave with phase correction

Output frequency: 60 Hz +/- 1 Hz

Battery low voltage alarm: 21.0 +/- 0.5 Volts

Battery low voltage shutdown: 20.0 +/- 0.5 Volts

No load current @ 24V: < 0.4 Amps

Full load efficiency: 90%

1/3 load efficiency: 95%

No load minimum operating temperature: -15 degrees Celsius

Full load maximum operating temperature: 55 +/- 5 degrees Celsius (automatic shutdown)

No load draw: Switch on – <1 amp DC. Switch off – <.2 mADC

AC Output Socket Type: quadruple Type 2 -3 prong

High input voltage protection: 34.5V

Low input voltage shutdown: 20.0V

Internal fuse protection

Product size (L x W x H): 16.92”X 7.95”X 6.1”

Unit Weight 16.72 lbs

Boxed Weight 20 lbs

UL maximum recommended per outlet 1500W

Additional information

Brand	AIMS Power
Voltage	24
