Rover Li 30 Amp MPPT Solar Charge Controller

Package Includes Rover Amp MPPT Solar Charge Controller xRemote Temperature Sensor xMounting Brackets XOptions BT Bluetooth Module x

Nominal System Voltage:
12/24V (Auto-Detect for Non-Lithium types)

Rated Charge Current:
30A

Max. PV Input Voltage:
95 VDC

Max. PV Input Power:
12V/400W, 24V/800W

Power Consumption:
＜100mA/12V; ＜58mA/24V

Max Battery Voltage:
32V

Ground Type:
Negative

Electrical Protection:
Overcharging, over-discharging, overload, and short circuit.Capable of charging over-discharged lithium batteries.

Protection Level:
IP32

Operating Temperature Range:
-35°C to 45°C; -31°F to 113°F

Storage Temperature Range:
-35°C to 75°C; -31°F to 167°F

Operating / Storage Humidity:
≤ 90%, No Condensation

Temperature Compensation:
-3mV/°C/2V

opc:


Dimensions:
238 x 172 x 77 mm; 9.38 x 6.78 x 3.05 in

Weight:
4.4 lbs / 2.0 kg

Max. Terminals Size:
8 AWG 10mm2

opc:


CE:
YES

FCC Class B Part 15 Compliant:
YES

Material and workmanship warranty:
2 Year

opc:


Compatible PWM Charge Controller:
RNG-CTRL-WND10/RNG-CTRL-WND30-LI/RNG-CTRL-ADV30-LI

Compatible MPPT Charge Controller:
RNG-CTRL-RVR20/RNG-CTRL-RVR30/ RNG-CTRL-RVR40/RNG-CTRL-RVR60S/ RNG-CTRL-RVR100

Compatible App:
Renogy DC Home App available in both the App Store and Google Play

opc:


Communication Range:
≤82ft (25m)

Cable Length:
16.4 ft (5.00m )

Dimensions:
9.38 x 6.78 x 3.05 in (238 x 172 x 77 mm)

Weight:
4.58oz (130g )

Operation Temperature:
-4°F to 185°F (-20℃~85℃)

opc:


Communication Protocol:
RS232

Port Type:
RJ12

Input Voltage:
5V

Protection Grade:
IP54

Standby Power Consumption:
0.04W

Operating Power Consumption:
0.05W

Serial Baud Rate:
Fixed Baud Rate 9600bps

opc:


FCC Class B Part 15 Compliant:
YES

opc:


Material and workmanship warranty:
2 Year

opc:
